General Specs |
| Product Weight (lbs.) | 108 |
| Color | Black Stainless Steel |
| Number of Cycles | 7 |
| Depth (in.) | 24 |
| Height (in.) | 34 |
| Interior (Settings) | 16 |
| Noise level (dB) | 42 |
| Tub Material | Stainless Steel |
| Width (in.) | 23.75 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Appliance Fit Width (in.) | 24 |
| Color Finish Name | Black Stainless Steel |
| Number Of Place Settings | 16 |
| ADA Compliant | No |
| Dishwasher Type | Built-In |
| Control Panel Type | Top |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 9 |
| Sound Rating Range | Quietest |
| Third Rack | No |
Features |
| Style | Built-In |
| Tub Type | Tall Tub |
| Control Type | Electronic Tactile Buttons
Top Controls |
| Dishwasher Control Features | 1 "Clean" Light, 1 "Sanitized" Light, 1 "Low Rinse Aid" Light
Audible End-of-Cycle Signal
LCD Control Display with Cycle Status Bar on door
Last Cycle Memory
Sabbath/Door Wake-up Mode
White LEDs |
| Wash System | 3-Level
800 Series |
| Wash System Features | 140+ Spray Jet Wash System
Automatic HotStart
Automatic Temperature Control
Bottle Jets
Deep Clean Silverware Jets
Drain Pump
Hidden Heater
Piranha™ Hard Food Disposer with removable filter
Quad Blade Middle Wash Arm
Reversing Quad Blade Lower Wash Arm
Side Jets
Variable Speed Dual Pumps and Motors |
| Sensor | Clean Sensor |
| Wash Arms | 3 Wash Levels
Bottle Jets
Jets - Variable Pressure
Lower- Reversing Quad Blade
Middle - Quad Blade
Side Jets |
| Water Filtration System | 100% Filtration with Piranha Hard Food Disposer and Removable Filter |
| Dispenser | Electronic Low Rinse Aid Sensor
Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | Auto Sense
Express
Heavy Wash
Light Wash
Normal Wash
Rinse
eWash |
| Dishwasher Options | Bottle Jets
Child Lock
Delay Start 1-12 Hr.
Heated Dry
Pre Soak
Sani (NSF 184 Certified)
Start/Reset
Wash TempBoost
Wash Zone Lower Only
Wash Zone Upper Only |
| Rack Features | 2 Utility Shelves with Stem Safe - Upper
3-Piece Silverware Basket with Cell Covers
Adjustable Upper Rack
Ball-Tipped Tines
Fold-Down Tines - Lower
Fold-down tines - Upper |
| Racking Material | Nylon |
| Rack Color | Black Pearl |
| Upper Rack | 1 Rack handle
1/2 fixed tines, 1/2 fold down tines
2 Stem Safe Shelves
Ball-Tip Tines
Premium Height Adjustable |
| Lower Rack | 1 Rack handle
Ball-Tip Tines
Multi-Position Fold Down Tines |
| Dishwasher Drying Features | Fan Assist Dry
Power Dry - On/Off |
| Floor Protection | Floor Protect with Alert |
| Leveling System | 4 Leveling Legs |
| Latch | Pull with Handle |
| Showroom Power Mode | Yes |
| Exterior Style | Traditional |
Appearance |
| Door Style | Long Door with Top Controls |
| Installation | Built-Up Floor Capable
Flush Cabinet Installation
Side Installation or Top Installation Included |
| Door Appearance | Full-length door |
| Handle | Rounded Handle - Color Matched |
| Handle Color | Color-Matched |
Economical/Quiet |
| Quiet Features | Quiet Water Valve
Sealed Toe Kick
Tub Collar Trim |
| Motor Type | Variable Speed |
| Outer Wrap | Bitumen
Full-wrap Blanket |
| Door Insulation | Insulation
Mastic |
Weights and Dimensions |
| Cabinet Width | 24 in |
| Height w/ Legs Retracted - Minimum Height | 33 3/8 in |
| Height w/Legs Extended - Maximum Height | 34 5/8 in |
Power/Ratings |
| Calrod Heater Watts | 1060 |
